Sandvik Coromant - M12x1.50 Metric Fine 6HX 4 Flute TiAlN Finish Solid Carbide Straight Flute Machine Tap - Right Hand Thread, 102.78mm OAL, 20mm Thread Length
Item #: 49636764
Brand: Sandvik Coromant
Model #: 6183255
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Titanium Aluminum Nitride (TiAlN) has a higher hardness and oxidation temperature versus TiN and TiCN. As a result, it is particularly advantageous for higher speed operations in a variety of steel machining applications.
| Product Specifications | |
|---|---|
| Tap Type | Machine Tap |
| Thread Size (mm) | M12x1.50 |
| Class of Fit | 6HX |
| Number of Flutes | 4 |
| Material | Solid Carbide |
| Finish/Coating | TiAlN |
| Thread Direction | Right Hand |
| Through Coolant | Through Coolant |
| Thread Standard | Metric Fine |
| Overall Length (Decimal Inch) | 4.04646 |
| Overall Length (mm) | 102.78 |
| Series/List | CoroTap 100 |
| Thread Length (Decimal Inch) | 0.7874 |
| Thread Length (mm) | 20.00 |
| Tapping Depth (mm) | 73 |
| Shank Diameter (Decimal Inch) | 0.3543 |
| Shank Diameter (mm) | 9.00 |
| Material Application | Cast Iron |
