Sandvik Coromant - 300mm OAL, 40mm Shank Diam, R/LAF151.37 Indexable Boring Bar - N151.3-600-50- 7G Insert
Item #: 49513054
Brand: Sandvik Coromant
Model #: 5734812
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Toolholder Style | R/LAF151.37 |
| Series | T-Max Q-Cut |
| Hand of Holder | Left Hand |
| Overall Length (mm) | 300.00 |
| Overall Length (Decimal Inch) | 11.8110 |
| Shank Diameter (mm) | 40.00 |
| Shank Diameter (Decimal Inch) | 1.5748 |
| Insert Compatibility | N151.3-600-50- 7G |
| Through Coolant | Yes |
| Rake | Neutral |
| Neck Diameter (Decimal Inch) | 1.5748 |
| Lead Angle | 90 |
| Back of Bar to Cutting Edge (mm) | 300.00 |
| Back of Bar to Cutting Edge (Decimal Inch) | 11.8110 |
| Center to Cutting Edge (mm) | 20.80 |
| Center to Cutting Edge (Decimal Inch) | 0.8189 |
| Rake Angle | 0 |
| Complete Insert Compatibility | N151.3-600-50- 7G |
| Toolholder Material | Steel |
