Seco - 100mm Cut Diam, 32mm Arbor Hole, 9mm Max Depth of Cut, 88° Indexable Chamfer & Angle Face Mill - 8 Inserts, SNMU1204.. Insert, Right Hand Cut, 8 Flutes, Through Coolant, Series R220.88-12
Item #: 47590823
Brand: Seco
Model #: 47076
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 100 |
| Cutting Diameter (Decimal Inch) | 3.9764 |
| Arbor Hole Diameter (mm) | 32.00 |
| Lead Angle | 88 |
| Overall Height (mm) | 50 |
| Insert Compatibility | SNMU1204.. |
| Series | R220.88-12 |
| Through Coolant | Yes |
| Maximum Depth of Cut (mm) | 9.00 |
| Number of Cutter Inserts | 8 |
| Insert Holding Method | Screw |
| Cutter Style | R220.88 |
| Number of Flutes | 8 |
| Hub Diameter (mm) | 77.00 |
| Keyway Width (mm) | 14.40 |
| Maximum RPM | 8900 |
| Cutting Direction | Right Hand |
| Pitch | Normal |
| Toolholder Material | Stainless Steel |
