Dorian Tool - External Thread, Left Hand Cut, 1" Shank Width x 1" Shank Height Indexable Threading Toolholder - 5" OAL, Laydown 16-G60 Insert Compatibility, SE Toolholder, Series Laydown Jet-Stream
Item #: 47152954
Brand: Dorian Tool
Model #: 73310158437
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Type | External |
| Hand of Holder | Left Hand |
| Shank Width/Diameter (mm) | 25.40 |
| Shank Width/Diameter (Decimal Inch) | 1.0000 |
| Shank Width/Diameter (Inch) | 1 |
| Shank Height (Inch) | 1 |
| Shank Height (Decimal Inch) | 1.0000 |
| Overall Length (Decimal Inch) | 5.0000 |
| Overall Length (mm) | 127.00 |
| Overall Length (Inch) | 5 |
| Insert Compatibility | Laydown 16-G60 |
| Series | Laydown Jet-Stream |
| Toolholder Style | SE |
| Through Coolant | No |
| Multi-Use Tool | No |
| Insert Holding Method | Screw |
| Back of Bar to Cutting Edge (Decimal Inch) | 1.0000 |
| Head Length (Decimal Inch) | 1.1000 |
| Shank Length (Decimal Inch) | 3.9000 |
| Insert Inscribed Circle (mm) | 9.53 |
| Insert Inscribed Circle (Inch) | 3/8 |
| Insert Inscribed Circle (Decimal Inch) | 0.3750 |
