![Recoil - 1,000 Inserts, 1/4-28 UNF, 2D, Stainless Steel Screw-Locking Insert - 11-3/8 Free Coils, 1/2" OAL, 0.306 to 0.326" OD, Tangless, Bright Finish - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/4660017-21_5112613d-1246-4706-97b8-9706fbad5214_1024x1024.jpg?v=1586460942)
Recoil - 1,000 Inserts, 1/4-28 UNF, 2D, Stainless Steel Screw-Locking Insert - 11-3/8 Free Coils, 1/2" OAL, 0.306 to 0.326" OD, Tangless, Bright Finish
Item #: 46600185
Brand: Recoil
Model #: TL14044
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 1/4-28 |
Overall Insert Length (Decimal Inch) | 0.5000 |
Overall Insert Length (mm) | 12.70 |
Tang | No |
Tang | Tangless |
Length to Diameter Ratio | 2D |
Length to Diameter Ratio | 2D |
Number of Inserts | 1000 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.3060 |
Maximum Outside Diameter (Decimal Inch) | 0.3260 |
Finish/Coating | Bright |
Number of Free Coils | 11-3/8 |
Number of Free Coils | 11-3/8 |
Maximum Locking Torque (In/Lb) | 30 |
Minimum Break Away Torque (In/Lb) | 3.50 |
Thread Standard | UNF |
Material Grade | 304 |
