Recoil - 1,000 Inserts, #10-24 UNC, 1-1/2D, Stainless Steel Screw-Locking Insert - 5 Free Coils, 0.285" OAL, 0.244 to 0.259" OD, Tangless, Bright Finish
Item #: 46600169
Brand: Recoil
Model #: TL13603
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #10-24 |
Overall Insert Length (Decimal Inch) | 0.2850 |
Overall Insert Length (mm) | 7.24 |
Tang | No |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 1000 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.2440 |
Maximum Outside Diameter (Decimal Inch) | 0.2590 |
Finish/Coating | Bright |
Number of Free Coils | 5 |
Number of Free Coils | 5 |
Maximum Locking Torque (In/Lb) | 13 |
Minimum Break Away Torque (In/Lb) | 2.00 |
Thread Standard | UNC |
Material Grade | 304 |
