Accupro - CAT40 Dual Contact Taper Shank 1/2" Hole End Mill Holder/Adapter - 1-3/8" Nose Diam, 5" Projection, Through-Spindle & DIN Flange Coolant
Item #: 42832725
Brand: Accupro
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Shank Type | Dual Contact Taper |
Taper Size | CAT40 |
Hole Diameter (Inch) | 1/2 |
Nose Diameter (mm) | 35.05 |
Nose Diameter (Inch) | 1-3/8 |
Projection (mm) | 127.00 |
Projection (Inch) | 5 |
Projection (Decimal Inch) | 5.0000 |
Through Coolant | Yes |
Clamping Depth (mm) | 38.10 |
Clamping Depth (Inch) | 1-1/2 |
Clamping Depth (Decimal Inch) | 1.5000 |
Overall Length (Decimal Inch) | 7.6870 |
Overall Length (mm) | 195.24 |
Balanced to (RPM) | 30000 |
TIR (Decimal Inch) | 0.0002 |
Coolant Type | Through-Spindle & DIN Flange |
Retention Knob Thread Size | 5/8-11 |
