Samchully - 1 Spindle, 658mm Horizontal & Vertical CNC Rotary Table - 1000 kg (2200 Lb) Max Horiz Load, 410mm Centerline Height, 372mm Through Hole
Item #: 39473517
Brand: Samchully
Model #: S650I5HP
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Indexer Type | Rotary Table |
| Number of Spindles | 1 |
| Collet Compatibility | None |
| Maximum RPM | 25 |
| Table Diameter (mm) | 658.00 |
| Setting Position | Horizontal; Vertical |
| Maximum Horizontal Load Capacity (Lb.) | 2200 |
| Maximum Horizontal Load Capacity (kg) | 1000 |
| Maximum Vertical Load Capacity (Lb.) | 880 |
| Maximum Vertical Load Capacity (kg) | 400 |
| Centerline Height (mm) | 410.00 |
| Through Hole Size (mm) | 372.00 |
| Repeatability (sec.) | 4.00 |
| Number of T-Slots | 8 |
| Motor Type | AC Servo |
