Walter-Prototyp - 0.4035" Cutting Diam, 3 Flute, Solid Carbide Helical Flute Thread Mill - Internal Thread, 21mm LOC, 90mm OAL, 14mm Shank Diam
Item #: 36375848
Brand: Walter-Prototyp
Model #: 5910477
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Titanium aluminum nitride (TiAlN) has a higher hardness than TiN and TiCN. It is extremely heat resistant and used for high speed applications on stainless steels, nickel and titanium alloys.
Product Specifications | |
---|---|
Pitch (mm) | 1.75 |
Material | Solid Carbide |
Thread Type | Internal |
Shank Diameter (mm) | 14 |
Number of Flutes | 3 |
Cutting Diameter (Decimal Inch) | 0.4035 |
Cutting Diameter (mm) | 10.25 |
Length of Cut (Decimal Inch) | 0.8268 |
Length of Cut (mm) | 21.00 |
Finish/Coating | TiAlN |
Through Coolant | Through Coolant |
Overall Length (Decimal Inch) | 3.5433 |
Overall Length (mm) | 90 |
Flute Direction | Right Hand |
Cutting Diameter Tolerance (mm) | -0.03 to +0.03 |
Shank Diameter Tolerance (mm) | h6 |
