Heli-Coil - Single Insert, 1/4-20 UNC, 2D, Stainless Steel Screw Locking Insert - 8 Free Coils, 1/2 Inch Overall Length, 0.31 to 0.33 Inch Outside Diameter, with Tang, Primer Free Coating, 304 Material Grade
Item #: 32886442
Brand: Heli-Coil
Model #: A3585-4CNPF500
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 1/4-20 |
Overall Insert Length (Decimal Inch) | 0.5000 |
Tang | Tangless |
Length to Diameter Ratio | 2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.3100 |
Maximum Outside Diameter (Decimal Inch) | 0.3300 |
Finish/Coating | Primer Free |
Number of Free Coils | 8 |
Maximum Locking Torque (In/Lb) | 30 |
Minimum Break Away Torque (In/Lb) | 4.50 |
Thread Standard | UNC |
Material Grade | 304 |
