Heli-Coil - Single Insert, 1/2-20 UNF, 1D, Nitronic 60 Stainless Steel Screw Locking Insert - 7-7/8 Free Coils, 1/2 Inch Overall Length, 0.592 to 0.617 Inch Outside Diameter, with Tang
Item #: 32886376
Brand: Heli-Coil
Model #: A3591-8EN500
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | 1/2-20 |
| Overall Insert Length (Decimal Inch) | 0.5000 |
| Tang | Tangless |
| Length to Diameter Ratio | 1D |
| Number of Inserts | 1 |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.5920 |
| Maximum Outside Diameter (Decimal Inch) | 0.6170 |
| Number of Free Coils | 7-7/8 |
| Maximum Locking Torque (In/Lb) | 150 |
| Mininum Break Away Torque (oz-in) | 18.00 |
| Minimum Break Away Torque (In/Lb) | 18.00 |
| Thread Standard | UNF |
