![Heli-Coil - Single Insert, 5/16-18 UNC, 1D, Nitronic 60 Stainless Steel Screw Locking Insert - 4 Free Coils, 5/16 Inch Overall Length, 0.38 to 0.4 Inch Outside Diameter, with Tang - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/5693743-11_3980d648-b547-4485-b31c-f68586188013_1024x1024.jpg?v=1586838589)
Heli-Coil - Single Insert, 5/16-18 UNC, 1D, Nitronic 60 Stainless Steel Screw Locking Insert - 4 Free Coils, 5/16 Inch Overall Length, 0.38 to 0.4 Inch Outside Diameter, with Tang
Item #: 32886129
Brand: Heli-Coil
Model #: A3585-5EN312
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 5/16-18 |
Overall Insert Length (Decimal Inch) | 0.3120 |
Tang | Tangless |
Length to Diameter Ratio | 1D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.3800 |
Maximum Outside Diameter (Decimal Inch) | 0.4000 |
Number of Free Coils | 4 |
Maximum Locking Torque (In/Lb) | 60 |
Minimum Break Away Torque (In/Lb) | 7.50 |
Thread Standard | UNC |
