![Heli-Coil - Single Insert, #10-24 UNC, 1-1/2D, Nitronic 60 Stainless Steel Screw Locking Insert - 5 Free Coils, 0.285 Inch Overall Length, 0.244 to 0.259 Inch Outside Diameter, with Tang - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/3288610-24_1024x1024.jpg?v=1586858626)
Heli-Coil - Single Insert, #10-24 UNC, 1-1/2D, Nitronic 60 Stainless Steel Screw Locking Insert - 5 Free Coils, 0.285 Inch Overall Length, 0.244 to 0.259 Inch Outside Diameter, with Tang
Item #: 32886103
Brand: Heli-Coil
Model #: A3585-3EN285
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #10-24 |
Overall Insert Length (Decimal Inch) | 0.2850 |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.2440 |
Maximum Outside Diameter (Decimal Inch) | 0.2590 |
Number of Free Coils | 5 |
Maximum Locking Torque (In/Lb) | 13 |
Minimum Break Away Torque (In/Lb) | 2.00 |
Thread Standard | UNC |
