Heli-Coil - Single Insert, M10x1.25 Metric Fine, 1-1/2D, Stainless Steel Screw Locking Insert - 9-1/2 Free Coils, 15mm Overall Length, 12.1 to 12.65mm Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 32886012
Brand: Heli-Coil
Model #: A5649-10CNW150
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M10x1.25 |
| Overall Insert Length (mm) | 15.00 |
| Tang | Tangless |
| Length to Diameter Ratio | 1-1/2D |
| Number of Inserts | 1 |
| Material | Stainless Steel |
| Minimum Outside Diameter (mm) | 12.10 |
| Maximum Outside Diameter (mm) | 12.65 |
| Finish/Coating | Dry Film Lubricant |
| Number of Free Coils | 9-1/2 |
| Maximum Locking Torque (N/m) | 10.00 |
| Minimum Break Away Torque (N/m) | 1.4000 |
| Thread Standard | Metric Fine |
| Material Grade | 304 |
