![Heli-Coil - Single Insert, M8x1 Metric Fine, 2D, Stainless Steel Screw Locking Insert - 13 Free Coils, 16mm Overall Length, 9.7 to 10.25mm Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/3288565-11_07968ca9-08da-47ad-87db-7c23be883d7d_1024x1024.jpg?v=1586460075)
Heli-Coil - Single Insert, M8x1 Metric Fine, 2D, Stainless Steel Screw Locking Insert - 13 Free Coils, 16mm Overall Length, 9.7 to 10.25mm Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 32885998
Brand: Heli-Coil
Model #: A5255-8CNW160
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | M8x1.00 |
Overall Insert Length (mm) | 16.00 |
Tang | Tangless |
Length to Diameter Ratio | 2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (mm) | 9.70 |
Maximum Outside Diameter (mm) | 10.25 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 13 |
Maximum Locking Torque (N/m) | 6.00 |
Minimum Break Away Torque (N/m) | 0.8000 |
Thread Standard | Metric Fine |
Material Grade | 304 |
