Heli-Coil - Single Insert, M10x1 Metric Fine, 1-1/2D, Stainless Steel Screw Locking Insert - 12 Free Coils, 15mm Overall Length, 11.95 to 12.5mm Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 32885956
Brand: Heli-Coil
Model #: A5255-10CNW150
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | M10x1.00 |
Overall Insert Length (mm) | 15.00 |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (mm) | 11.95 |
Maximum Outside Diameter (mm) | 12.50 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 12 |
Maximum Locking Torque (N/m) | 10.00 |
Minimum Break Away Torque (N/m) | 1.4000 |
Thread Standard | Metric Fine |
Material Grade | 304 |
