Heli-Coil - Single Insert, M4x0.7 Metric Coarse, 1-1/2D, Stainless Steel Screw Locking Insert - 6-1/8 Free Coils, 6mm Overall Length, 5.05 to 5.6mm Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade - Exact Industrial Supply

Heli-Coil - Single Insert, M4x0.7 Metric Coarse, 1-1/2D, Stainless Steel Screw Locking Insert - 6-1/8 Free Coils, 6mm Overall Length, 5.05 to 5.6mm Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade


Item #: 32885824
Brand: Heli-Coil
Model #: A4184-4CNW060
Exact Tooling IR#: 04

Product Specifications
Thread Size M4x0.70
Overall Insert Length (mm) 6.00
Tang Tangless
Length to Diameter Ratio 1-1/2D
Number of Inserts 1
Material Stainless Steel
Minimum Outside Diameter (mm) 5.05
Maximum Outside Diameter (mm) 5.60
Finish/Coating Dry Film Lubricant
Number of Free Coils 6-1/8
Maximum Locking Torque (N/m) 0.90
Minimum Break Away Torque (N/m) 0.1600
Thread Standard Metric Coarse
Material Grade 304
$1.73

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It
