![Heli-Coil - Single Insert, M3x0.5 Metric Coarse, 1D, Stainless Steel Screw Locking Insert - 3-3/4 Free Coils, 3mm Overall Length, 3.8 to 4.35mm Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/3288579-23_1024x1024.jpg?v=1586460152)
Heli-Coil - Single Insert, M3x0.5 Metric Coarse, 1D, Stainless Steel Screw Locking Insert - 3-3/4 Free Coils, 3mm Overall Length, 3.8 to 4.35mm Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 32885790
Brand: Heli-Coil
Model #: A4184-3CNW030
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | M3x0.50 |
Overall Insert Length (mm) | 3.00 |
Tang | Tangless |
Length to Diameter Ratio | 1D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (mm) | 3.80 |
Maximum Outside Diameter (mm) | 4.35 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 3-3/4 |
Maximum Locking Torque (N/m) | 0.44 |
Minimum Break Away Torque (N/m) | 0.1000 |
Thread Standard | Metric Coarse |
Material Grade | 304 |
