Heli-Coil - Single Insert, M3.5x0.6 Metric Coarse, 1D, Stainless Steel Screw Locking Insert - 3-3/4 Free Coils, 3.5mm Overall Length, 4.4 to 4.95mm Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 32885766
Brand: Heli-Coil
Model #: A4184-3.5CNW035
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | M3.5x0.60 |
Overall Insert Length (mm) | 3.50 |
Tang | Tangless |
Length to Diameter Ratio | 1D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (mm) | 4.40 |
Maximum Outside Diameter (mm) | 4.95 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 3-3/4 |
Maximum Locking Torque (N/m) | 0.68 |
Minimum Break Away Torque (N/m) | 0.1200 |
Thread Standard | Metric Coarse |
Material Grade | 304 |
