Heli-Coil - Single Insert, M2.2x0.45 Metric Coarse, 1-1/2D, Stainless Steel Screw Locking Insert - 5-3/8 Free Coils, 3.3mm Overall Length, 2.8 to 3mm Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 32885717
Brand: Heli-Coil
Model #: A4184-2.2CNW033
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | M2.2x0.45 |
Overall Insert Length (mm) | 3.30 |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (mm) | 2.80 |
Maximum Outside Diameter (mm) | 3.00 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 5-3/8 |
Maximum Locking Torque (N/m) | 0.14 |
Minimum Break Away Torque (N/m) | 0.0200 |
Thread Standard | Metric Coarse |
Material Grade | 304 |
