Heli-Coil - Single Insert, M2.2x0.45 Metric Coarse, 1D, Stainless Steel Screw Locking Insert - 3-1/8 Free Coils, 2.2mm Overall Length, 2.8 to 3mm Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 32885709
Brand: Heli-Coil
Model #: A4184-2.2CNW022
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M2.2x0.45 |
| Overall Insert Length (mm) | 2.20 |
| Tang | Tangless |
| Length to Diameter Ratio | 1D |
| Number of Inserts | 1 |
| Material | Stainless Steel |
| Minimum Outside Diameter (mm) | 2.80 |
| Maximum Outside Diameter (mm) | 3.00 |
| Finish/Coating | Dry Film Lubricant |
| Number of Free Coils | 3-1/8 |
| Maximum Locking Torque (N/m) | 0.14 |
| Minimum Break Away Torque (N/m) | 0.0200 |
| Thread Standard | Metric Coarse |
| Material Grade | 304 |
