Heli-Coil - Single Insert, 1/2-20 UNF, 2D, Stainless Steel Screw Locking Insert - 16-7/8 Free Coils, 1 Inch Overall Length, 0.592 to 0.617 Inch Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 32885626
Brand: Heli-Coil
Model #: A3591-8CNW1000
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 1/2-20 |
Overall Insert Length (Decimal Inch) | 1.0000 |
Tang | Tangless |
Length to Diameter Ratio | 2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.5920 |
Maximum Outside Diameter (Decimal Inch) | 0.6170 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 16-7/8 |
Maximum Locking Torque (In/Lb) | 150 |
Mininum Break Away Torque (oz-in) | 18.00 |
Minimum Break Away Torque (In/Lb) | 18.00 |
Thread Standard | UNF |
Material Grade | 304 |
