![Heli-Coil - Single Insert, 5/16-24 UNF, 1D, Stainless Steel Screw Locking Insert - 5-1/2 Free Coils, 5/16 Inch Overall Length, 0.38 to 0.4 Inch Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/3288552-23_1024x1024.jpg?v=1586838612)
Heli-Coil - Single Insert, 5/16-24 UNF, 1D, Stainless Steel Screw Locking Insert - 5-1/2 Free Coils, 5/16 Inch Overall Length, 0.38 to 0.4 Inch Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 32885527
Brand: Heli-Coil
Model #: A3591-5CNW312
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 5/16-24 |
Overall Insert Length (Decimal Inch) | 0.3120 |
Tang | Tangless |
Length to Diameter Ratio | 1D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.3800 |
Maximum Outside Diameter (Decimal Inch) | 0.4000 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 5-1/2 |
Maximum Locking Torque (In/Lb) | 60 |
Mininum Break Away Torque (oz-in) | 6.50 |
Minimum Break Away Torque (In/Lb) | 6.50 |
Thread Standard | UNF |
Material Grade | 304 |
