Heli-Coil - Single Insert, 7/16-14 UNC, 1D, Stainless Steel Screw Locking Insert - 4-1/2 Free Coils, 7/16 Inch Overall Length, 0.526 to 0.551 Inch Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 32885386
Brand: Heli-Coil
Model #: A3585-7CNW438
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 7/16-14 |
Overall Insert Length (Decimal Inch) | 0.4380 |
Tang | Tangless |
Length to Diameter Ratio | 1D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.5260 |
Maximum Outside Diameter (Decimal Inch) | 0.5510 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 4-1/2 |
Maximum Locking Torque (In/Lb) | 100 |
Minimum Break Away Torque (In/Lb) | 16.50 |
Thread Standard | UNC |
Material Grade | 304 |
