![Heli-Coil - Single Insert, 1/4-20 UNC, 2-1/2D, Stainless Steel Screw Locking Insert - 10-3/8 Free Coils, 5/8 Inch Overall Length, 0.31 to 0.33 Inch Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/3288528-23_1024x1024.jpg?v=1586838485)
Heli-Coil - Single Insert, 1/4-20 UNC, 2-1/2D, Stainless Steel Screw Locking Insert - 10-3/8 Free Coils, 5/8 Inch Overall Length, 0.31 to 0.33 Inch Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 32885287
Brand: Heli-Coil
Model #: A3585-4CNW625
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 1/4-20 |
Overall Insert Length (Decimal Inch) | 0.6250 |
Tang | Tangless |
Length to Diameter Ratio | 2-1/2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.3100 |
Maximum Outside Diameter (Decimal Inch) | 0.3300 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 10-3/8 |
Maximum Locking Torque (In/Lb) | 30 |
Minimum Break Away Torque (In/Lb) | 4.50 |
Thread Standard | UNC |
Material Grade | 304 |
