Heli-Coil - Single Insert, #2-56 UNC, 3D, Stainless Steel Screw Locking Insert - 11-7/8 Free Coils, 0.258 Inch Overall Length, 0.11 to 0.119 Inch Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 32885089
Brand: Heli-Coil
Model #: A3585-02CNW258
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | #2-56 |
| Overall Insert Length (Decimal Inch) | 0.2580 |
| Tang | Tangless |
| Length to Diameter Ratio | 3D |
| Number of Inserts | 1 |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.1100 |
| Maximum Outside Diameter (Decimal Inch) | 0.1190 |
| Finish/Coating | Dry Film Lubricant |
| Number of Free Coils | 11-7/8 |
| Maximum Locking Torque (oz-in) | 20 |
| Mininum Break Away Torque (oz-in) | 3.00 |
| Thread Standard | UNC |
| Material Grade | 304 |
