Heli-Coil - Single Insert, M12x1.5 Metric Fine, 1D, Stainless Steel Screw Locking Insert - 6 Free Coils, 12mm Overall Length, 14.25 to 14.95mm Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 32885022
Brand: Heli-Coil
Model #: A5145-12CN120
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M12x1.50 |
| Overall Insert Length (mm) | 12.00 |
| Tang | Tangless |
| Length to Diameter Ratio | 1D |
| Number of Inserts | 1 |
| Material | Stainless Steel |
| Minimum Outside Diameter (mm) | 14.25 |
| Maximum Outside Diameter (mm) | 14.95 |
| Finish/Coating | Bright |
| Number of Free Coils | 6 |
| Maximum Locking Torque (N/m) | 15.00 |
| Minimum Break Away Torque (N/m) | 2.2000 |
| Thread Standard | Metric Fine |
| Material Grade | 304 |
