Heli-Coil - Single Insert, M7x1 Metric Coarse, 1-1/2D, Stainless Steel Screw Locking Insert - 8 Free Coils, 10.5mm Overall Length, 8.65 to 9.2mm Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 32885014
Brand: Heli-Coil
Model #: A4184-7CN105
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | M7x1.00 |
Overall Insert Length (mm) | 10.50 |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (mm) | 8.65 |
Maximum Outside Diameter (mm) | 9.20 |
Finish/Coating | Bright |
Number of Free Coils | 8 |
Maximum Locking Torque (N/m) | 4.40 |
Minimum Break Away Torque (N/m) | 0.6000 |
Thread Standard | Metric Coarse |
Material Grade | 304 |
