Heli-Coil - Single Insert, M2.5x0.45 Metric Coarse, 2D, Stainless Steel Screw Locking Insert - 8-1/8 Free Coils, 5mm Overall Length, 3.2 to 3.7mm Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 32884959
Brand: Heli-Coil
Model #: A4184-2.5CN050
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | M2.5x0.45 |
Overall Insert Length (mm) | 5.00 |
Tang | Tangless |
Length to Diameter Ratio | 2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (mm) | 3.20 |
Maximum Outside Diameter (mm) | 3.70 |
Finish/Coating | Bright |
Number of Free Coils | 8-1/8 |
Maximum Locking Torque (N/m) | 0.22 |
Minimum Break Away Torque (N/m) | 0.0600 |
Thread Standard | Metric Coarse |
Material Grade | 304 |
