Heli-Coil - Single Insert, 3/8-24 UNF, 3D, Stainless Steel Screw Locking Insert - 23-1/8 Free Coils, 1-1/8 Inch Overall Length, 0.448 to 0.468 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 32884918
Brand: Heli-Coil
Model #: A3591-6CN1125
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 3/8-24 |
Overall Insert Length (Decimal Inch) | 1.1250 |
Tang | Tangless |
Length to Diameter Ratio | 3D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.4480 |
Maximum Outside Diameter (Decimal Inch) | 0.4680 |
Finish/Coating | Bright |
Number of Free Coils | 23-1/8 |
Maximum Locking Torque (In/Lb) | 80 |
Mininum Break Away Torque (oz-in) | 9.50 |
Minimum Break Away Torque (In/Lb) | 9.50 |
Thread Standard | UNF |
Material Grade | 304 |
