Heli-Coil - Single Insert, #12-24 UNC, 1-1/2D, Stainless Steel Screw Locking Insert - 6 Free Coils, 0.324 Inch Overall Length, 0.27 to 0.285 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 32884801
Brand: Heli-Coil
Model #: A3585-1CN324
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #12-24 |
Overall Insert Length (Decimal Inch) | 0.3240 |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.2700 |
Maximum Outside Diameter (Decimal Inch) | 0.2850 |
Finish/Coating | Bright |
Number of Free Coils | 6 |
Maximum Locking Torque (In/Lb) | 24 |
Minimum Break Away Torque (In/Lb) | 3.00 |
Thread Standard | UNC |
Material Grade | 304 |
