Miniature Ball Bearing: 4 mm Bore Dia, 13 mm OD, 12.95 mm OAW 1 Row
Item #: 30665871
Brand: Tritan
Model #: 624 2RS PRX
Product Specifications
| Bore Type | Round |
| Type | Miniature |
| Bore Diameter (mm) | 4.00 |
| Bore Diameter (Decimal Inch) | 0.1570 |
| Outside Diameter (Decimal Inch - 4 Decimals) | 0.5100 |
| Outside Diameter | 13.00 |
| Style | Double Seal |
| Bore Diameter | 0.1570 |
| Flanged | No |
| Flange Type | Without Flange |
| Inner Ring Width (Decimal Inch) | 0.2000 |
| Width (Mm - 2 Decimals) | 12.95 |
| Maximum Operating Temperature F | 212 |
| Width (Decimal Inch - 4 Decimals) | 0.5100 |
| Number Of Rows | 1 |
| Minimum Operating Temperature F | -20 |
