Item #: 29449196
Brand: Seco
Model #: 00032440
Product Specifications
| Milling Diameter | 40.00 mm |
| Maximum Depth Of Cut | 60.00 mm |
| Maximum Ramping Angle | 45 |
| Shank Diameter | 32.00 mm |
| Shank Type | Weldon Flat |
| Compatible Insert Style | SCET; 218.20 |
| Compatible Insert Size Code | 200; 120612 |
| Toolholder Style | R218.20 |
| Series | R218.20 |
| Overall Length (mm) | 159.40 |
| Overall Length (Decimal Inch) | 159.40 |
| Overall Length (Inch) | 159.40 |
| Maximum Rpm | 7200.000 |
| Tool Application | Profile Milling; Semi-Finishing |
| Tool Performance | High Performance |
| Insert Holding Method | Screw |
| Toolholder Material | Steel |
| Through Coolant | Normal Pressure; High Pressure |
| Tapered Neck | No |
| Number of Flutes | 2 |
