Automation Systems Interconnect - Circuit Breakers; Circuit Breaker Type: Miniature Circuit Breaker ; Amperage: 2 ; Number of Poles: 3 ; Breaking Capacity: 10 kA @ 400/415 VAC; 7.5kA @ 480VAC ; Tripping Mechanism: Thermal-Magnetic ; Terminal Connection T - Exact Industrial Supply

Automation Systems Interconnect - Circuit Breakers; Circuit Breaker Type: Miniature Circuit Breaker ; Amperage: 2 ; Number of Poles: 3 ; Breaking Capacity: 10 kA @ 400/415 VAC; 7.5kA @ 480VAC ; Tripping Mechanism: Thermal-Magnetic ; Terminal Connection T


Item #: 28743268
Brand: Automation Systems Interconnect
Model #: NDB2-63C2-3

Product Specifications

Circuit Breakers; Circuit Breaker Type: Miniature Circuit Breaker ; Amperage: 2 ; Number of Poles: 3 ; Breaking Capacity: 10 kA @ 400/415 VAC; 7.5kA @ 480VAC ; Tripping Mechanism: Thermal-Magnetic ; Terminal Connection Type: Screw
Circuit Breaker Type Miniature Circuit Breaker
Amperage 2
Number of Poles 3
Breaking Capacity 10 kA @ 400/415 VAC; 7.5kA @ 480VAC
Tripping Mechanism Thermal-Magnetic
Terminal Connection Type Screw
Mounting Type DIN Rail
Voltage 480 VAC
Wire Size (AWG) 18-2
Durability 20000 Cycles
Maximum Operating Temperature (F) 158
Minimum Operating Temperature (F) -40
Overall Depth (Decimal Inch) 3.1
Overall Depth (mm) 79
Overall Depth (Inch) 3.1
Overall Height (mm) 81.5
Overall Height (Inch) 3.2
Overall Height (Decimal Inch) 3.2
Overall Length (mm) 79
Overall Length (Inch) 3.1
Overall Length (Decimal Inch) 3.1
Overall Width (mm) 52.8
Overall Width (Inch) 2.07
Overall Width (Decimal Inch) 2.07
Standards Met UL 1077
Reset Actuator Type Toggle Switch
$50.82
