Miniature Ball Bearing: 7 mm Bore Dia, 14 mm OD, 13.97 mm OAW 1 Row, 55 lb Static Load Capacity, 126 lb Dynamic Load Capacity
Item #: 19837277
Brand: Tritan
Model #: L1470 ZZ SRL
Product Specifications
| Bore Type | Round |
| Type | Miniature |
| Bore Diameter (mm) | 7.00 |
| Bore Diameter (Decimal Inch) | 0.2760 |
| Outside Diameter (Decimal Inch - 4 Decimals) | 0.5500 |
| Outside Diameter | 14.00 |
| Dynamic Load Capacity (Lb.) | 126 |
| Style | Double Shield |
| Static Load Capacity | 55 |
| Bore Diameter | 0.2760 |
| Flanged | No |
| Flange Type | Without Flange |
| Inner Ring Width (Decimal Inch) | 0.2000 |
| Width (Mm - 2 Decimals) | 13.97 |
| Maximum Operating Temperature F | 212 |
| Width (Decimal Inch - 4 Decimals) | 0.5500 |
| Number Of Rows | 1 |
| Minimum Operating Temperature F | -20 |
