![Corner Radius End Mill: 3/4″ Dia, 2-1/4″ LOC, 0.06″ Radius, 3 Flutes, Solid Carbide 5″ OAL, 3/4″ Shank Dia, 42 ° Helix, Bright/Uncoated, Corner Radius End, Centercutting](http://exactindustrialsupply.com/cdn/shop/products/1819205-21_0bd84da1-c4bf-4838-9827-e9087a2f2ccf_1024x1024.jpg?v=1675056450)
Corner Radius End Mill: 3/4″ Dia, 2-1/4″ LOC, 0.06″ Radius, 3 Flutes, Solid Carbide 5″ OAL, 3/4″ Shank Dia, 42 ° Helix, Bright/Uncoated, Corner Radius End, Centercutting
Item #: 18200949
Brand: SC Tool
Model #: 10249
Product Specifications
Mill Diameter (Decimal Inch) | 0.7500 |
Mill Diameter (Inch) | 3/4 |
Length of Cut (Inch) | 2-1/4 |
Corner Radius (Decimal Inch) | 0.0600 |
Number Of Flutes | 3 |
End Mill Material | Solid Carbide |
Extended Reach | No |
End Type | Corner Radius |
Flute Type | Helical |
Helix Angle | 42 |
Centercutting | Yes |
Variable Index | No |
Variable Helix | No |
Shank Diameter (Inch) | 3/4 |
Overall Length (Inch) | 5 |
Overall Length (Decimal Inch) | 5.0000 |
Cutting Direction | Right Hand |
Flute Direction | Right Hand |
Single Or Double End | Single |
Manufacturers Catalog Number | AX30750-1840-12 |
Coating/Finish | Bright/Uncoated |
Length Of Cut (Decimal Inch - 4 Decimals) | 2.2500 |
