Square End Mill: 3/4'' Dia, 2-1/4'' LOC, 3/4'' Shank Dia, 5'' OAL, 6 Flutes, Solid Carbide Single End, AlCrN Finish, Spiral Flute, Variable Helix, Centercutting, RH Cut, RH Flute
Item #: 18199158
Brand: SC Tool
Model #: 20663
Product Specifications
Mill Diameter (Inch) | 3/4 |
Mill Diameter (Decimal Inch) | 0.7500 |
Mill Diameter (mm) | 19.05 |
Number Of Flutes | 6 |
Length of Cut (Inch) | 2-1/4 |
End Mill Material | Solid Carbide |
End Type | Single |
Centercutting | Yes |
Cutting Direction | Right Hand |
Shank Diameter (Inch) | 3/4 |
Finish/Coating | AlCrN |
Overall Length (Inch) | 5 |
Variable Helix | Yes |
Variable Index | Yes |
Extended Reach | No |
Length Of Cut Range (Decimal Inch) | 2.0000+ |
Length of Cut (Decimal Inch) | 2.2500 |
Material Grade | Submicron |
Shank Diameter (Decimal Inch) | 0.7500 |
Overall Length (Decimal Inch) | 5.0000 |
Flute Direction | Right Hand |
Flute Type | Spiral |
