Corner Radius End Mill: 3/4″ Dia, 1-3/4″ LOC, 0.03″ Radius, 3 Flutes, Solid Carbide 4″ OAL, 3/4″ Shank Dia, 42 ° Helix, ZrN Coated, Corner Radius End, Centercutting
Item #: 18196378
Brand: SC Tool
Model #: 10371
Product Specifications
Mill Diameter (Decimal Inch) | 0.7500 |
Mill Diameter (Inch) | 3/4 |
Length of Cut (Inch) | 1-3/4 |
Corner Radius (Decimal Inch) | 0.0300 |
Number Of Flutes | 3 |
End Mill Material | Solid Carbide |
Extended Reach | No |
End Type | Corner Radius |
Flute Type | Helical |
Helix Angle | 42 |
Centercutting | Yes |
Variable Index | No |
Variable Helix | No |
Shank Diameter (Inch) | 3/4 |
Overall Length (Inch) | 4 |
Overall Length (Decimal Inch) | 4.0000 |
Cutting Direction | Right Hand |
Flute Direction | Right Hand |
Single Or Double End | Single |
Manufacturers Catalog Number | AX30750-1432-06-SC13 |
Coating/Finish | ZrN |
Length Of Cut (Decimal Inch - 4 Decimals) | 1.7500 |
