Corner Radius End Mill: 3/4″ Dia, 1-3/4″ LOC, 0.06″ Radius, 6 Flutes, Solid Carbide 4″ OAL, 3/4″ Shank Dia, Variable ° Helix, AlCrN Coated, Corner Radius End, Centercutting
Item #: 18193607
Brand: SC Tool
Model #: 20650
Product Specifications
| Mill Diameter (Decimal Inch) | 0.7500 |
| Mill Diameter (Inch) | 3/4 |
| Length of Cut (Inch) | 1-3/4 |
| Corner Radius (Decimal Inch) | 0.0600 |
| Number Of Flutes | 6 |
| End Mill Material | Solid Carbide |
| Extended Reach | No |
| End Type | Corner Radius |
| Flute Type | Spiral |
| Helix Angle | Variable |
| Centercutting | Yes |
| Variable Index | Yes |
| Variable Helix | Yes |
| Shank Diameter (Inch) | 3/4 |
| Overall Length (Inch) | 4 |
| Overall Length (Decimal Inch) | 4.0000 |
| Cutting Direction | Right Hand |
| Flute Direction | Right Hand |
| Single Or Double End | Single |
| Manufacturers Catalog Number | SV60750-1432-12 |
| Coating/Finish | AlCrN |
| Length Of Cut (Decimal Inch - 4 Decimals) | 1.7500 |
