Air Cylinders; Type: Double Acting; Bore Size (Decimal Inch): 4; Rod Diameter (Decimal Inch): 1.0000; Stroke Length (Decimal Inch): 6.0000; Mounting Style: Flush Bottom; Port Size: 3/8; Port Type: NPT; Width (Decimal Inch): 4.5000; Length (Decimal Inch):
Item #: 17775719
Brand: Mead
Model #: FM-MS4-4X6
Product Specifications
| Type | Double Acting |
| Bore Size (Decimal Inch) | 4 |
| Rod Diameter (Decimal Inch) | 1.0000 |
| Stroke Length (Decimal Inch) | 6.0000 |
| Mounting Style | Flush Bottom |
| Port Size | 3/8 |
| Port Type | NPT |
| Width (Decimal Inch) | 4.5000 |
| Length (Decimal Inch) | 12.7500 |
| Mount Thread | 1/2-13 |
| Seal Material | Nitrile/Carbon |
| Maximum Working Pressure (psi) | 250.000 |
| Rod Thread Size | 3/4-16 |
| Cushions | None |
