Air Cylinders; Type: Double Acting; Bore Size (Decimal Inch): 4; Rod Diameter (Decimal Inch): 1.0000; Stroke Length (Decimal Inch): 8.0000; Mounting Style: Flush Bottom; Port Size: 3/8; Port Type: NPT; Width (Decimal Inch): 4.5000; Length (Decimal Inch):

Air Cylinders; Type: Double Acting; Bore Size (Decimal Inch): 4; Rod Diameter (Decimal Inch): 1.0000; Stroke Length (Decimal Inch): 8.0000; Mounting Style: Flush Bottom; Port Size: 3/8; Port Type: NPT; Width (Decimal Inch): 4.5000; Length (Decimal Inch):


Item #: 17775578
Brand: Mead
Model #: FM-MS4-4X8

Product Specifications

Type Double Acting
Bore Size (Decimal Inch) 4
Rod Diameter (Decimal Inch) 1.0000
Stroke Length (Decimal Inch) 8.0000
Mounting Style Flush Bottom
Port Size 3/8
Port Type NPT
Width (Decimal Inch) 4.5000
Length (Decimal Inch) 14.7500
Mount Thread 1/2-13
Seal Material Nitrile/Carbon
Maximum Working Pressure (psi) 250.000
Rod Thread Size 3/4-16
Cushions None
$489.84

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It
