Straight Flutes Tap: Metric, 5 Flutes, Semi-Bottoming, 6HX, Solid Carbide, TiCN Finish Right Hand, Series TC388
Item #: 17265620
Brand: Walter-Prototyp
Model #: 7559348
Product Specifications
| Tap Type | Straight Flute |
| Material | Solid Carbide |
| Coating/Finish | TiCN |
| Thread Size (mm) | M5 |
| Overall Length (mm) | 70.00 |
| Chamfer | Semi-Bottoming |
| Thread Standard | Metric |
| Thread Direction | Right Hand |
| Thread Length (Mm) ( - 3 Decimals) | 13.50 |
| Shank Diameter (mm) | 6.00 |
| Tapping Depth (mm) | 47.00 |
| Square Length (mm) | 4.90 |
| Series | TC388 |
| Shank Length (mm) | 8.00 |
| Class Of Fit | 6HX |
| Number Of Flutes | 5 |
| Coolant Through | No |
