Fork Terminals; Terminal Type: Locking; Insulation Type: Partially Insulated; Connection Type: Crimp; Compatible Wire Size (sq mm): 0.5-1.5; Stud Size (Inch): 4.3 mm; Stud Size (mm): 4.3; Stud Size (#): 8; Fork Width (Decimal Inch): 0.283 in; 7.2 mm; Fork
Item #: 14736326
Brand: Value Collection
Model #: LSNYS1-4
Product Specifications
| Terminal Type | Locking |
| Insulation Type | Partially Insulated |
| Connection Type | Crimp |
| Compatible Wire Size (sq mm) | 0.5-1.5 |
| Stud Size (Inch) | 4.3 mm |
| Stud Size (mm) | 4.3 |
| Stud Size (#) | 8 |
| Fork Width (Decimal Inch) | 0.283 in; 7.2 mm |
| Fork Width (mm) | 7.2 |
| Insulation Material | Nylon |
| Overall Length (Decimal Inch) | 0.87 in; 22 mm |
| Overall Length (mm) | 22 |
| Voltage | 600 V |
| Thickness (Decimal Inch) | 0.03 in; 0.75 mm |
| Thickness (mm) | 0.75 |
| Contact Material | Copper |
| Contact Plating | Tin |
