![Ball End Mill: 1″ Dia, 3″ LOC, 4 Flute, Solid Carbide 6″ OAL, 1″ Shank Dia, 30 ° Helix, Uncoated, Single End, Series 237](http://exactindustrialsupply.com/cdn/shop/products/1454817-21_1024x1024.jpg?v=1675051223)
Ball End Mill: 1″ Dia, 3″ LOC, 4 Flute, Solid Carbide 6″ OAL, 1″ Shank Dia, 30 ° Helix, Uncoated, Single End, Series 237
Item #: 14558803
Brand: GWS
Model #: 319520
Product Specifications
Mill Diameter (Inch) | 1 |
Mill Diameter (Decimal Inch) | 1.0000 |
Length of Cut (Inch) | 3 |
End Mill Material | Solid Carbide |
End Type | Ball |
Extended Reach | No |
Helix Angle | 30 |
Variable Index | No |
Variable Helix | No |
Shank Diameter (Inch) | 1 |
Shank Diameter (Decimal Inch) | 1.0000 |
Overall Length (Inch) | 6 |
Flute Direction | Right Hand |
Cutting Direction | Right Hand |
Series | 237 |
Centercutting | Yes |
Single Or Double End | Single |
Number Of Flutes | 4 |
Coating/Finish | Uncoated |
Length Of Cut (Decimal Inch - 4 Decimals) | 3.0000 |
Manufacturers Catalog Number | 5841000BN |
