Corner Radius End Mill: 3/4″ Dia, 1-5/8″ LOC, 0.09″ Radius, 5 Flutes, Solid Carbide 6″ OAL, 3/4″ Shank Dia, 37 ° Helix, AlCromax Coated, Corner Radius End, Centercutting, Series 265

Corner Radius End Mill: 3/4″ Dia, 1-5/8″ LOC, 0.09″ Radius, 5 Flutes, Solid Carbide 6″ OAL, 3/4″ Shank Dia, 37 ° Helix, AlCromax Coated, Corner Radius End, Centercutting, Series 265


Item #: 14558506
Brand: GWS
Model #: 317003

Product Specifications

Mill Diameter (Decimal Inch) 0.7500
Mill Diameter (Inch) 3/4
Length of Cut (Inch) 1-5/8
Corner Radius (Decimal Inch) 0.0900
Number Of Flutes 5
End Mill Material Solid Carbide
Extended Reach No
End Type Corner Radius
Flute Type Upcut
Helix Angle 37
Centercutting Yes
Variable Index Yes
Variable Helix Yes
Shank Diameter (Inch) 3/4
Overall Length (Inch) 6
Overall Length (Decimal Inch) 6.0000
Cutting Direction Right Hand
Flute Direction Right Hand
Single Or Double End Single
Manufacturers Catalog Number 537L75026090C15
Coating/Finish AlCromax
$203.46
