![Ball End Mill: 1″ Dia, 2″ LOC, 4 Flute, Solid Carbide 4″ OAL, 1″ Shank Dia, 40 ° Helix, AlCromax Coated, Single End, Series 252](http://exactindustrialsupply.com/cdn/shop/products/1454899-21_ea158518-c143-41a9-9a89-2949988232a0_1024x1024.jpg?v=1675050795)
Ball End Mill: 1″ Dia, 2″ LOC, 4 Flute, Solid Carbide 4″ OAL, 1″ Shank Dia, 40 ° Helix, AlCromax Coated, Single End, Series 252
Item #: 14550693
Brand: GWS
Model #: 316372
Product Specifications
Mill Diameter (Inch) | 1 |
Mill Diameter (Decimal Inch) | 1.0000 |
Length of Cut (Inch) | 2 |
End Mill Material | Solid Carbide |
End Type | Ball |
Extended Reach | No |
Helix Angle | 40 |
Variable Index | Yes |
Variable Helix | Yes |
Shank Diameter (Inch) | 1 |
Shank Diameter (Decimal Inch) | 1.0000 |
Overall Length (Inch) | 4 |
Flute Direction | Right Hand |
Cutting Direction | Right Hand |
Series | 252 |
Centercutting | Yes |
Single Or Double End | Single |
Number Of Flutes | 4 |
Coating/Finish | AlCromax |
Length Of Cut (Decimal Inch - 4 Decimals) | 2.0000 |
Manufacturers Catalog Number | 440V10032BNC15 |
