![Ball End Mill: 1″ Dia, 3 Flute, Solid Carbide 4″ OAL, 1″ Shank Dia, 37 ° Helix, ZrN Coated, Single End, Series 1028 & Alumigator](http://exactindustrialsupply.com/cdn/shop/products/2604654-21_ca4cf0c2-0ae2-4f56-b707-a8670ea1e5a8_1024x1024.jpg?v=1675177174)
Ball End Mill: 1″ Dia, 3 Flute, Solid Carbide 4″ OAL, 1″ Shank Dia, 37 ° Helix, ZrN Coated, Single End, Series 1028 & Alumigator
Item #: 14546527
Brand: GWS
Model #: 108750
Product Specifications
Mill Diameter (Inch) | 1 |
Mill Diameter (Decimal Inch) | 1.0000 |
Length of Cut (Inch) | 1-1/4 |
End Mill Material | Solid Carbide |
End Type | Ball |
Extended Reach | Yes |
Helix Angle | 37 |
Variable Index | No |
Variable Helix | No |
Shank Diameter (Inch) | 1 |
Shank Diameter (Decimal Inch) | 1.0000 |
Neck Length (Inch) | 2 |
Neck Length (Decimal Inch) | 2.0000 |
Reach Length (Inch) | 2 |
Reach Length (Decimal Inch) | 2.0000 |
Overall Length (Inch) | 4 |
Flute Direction | Right Hand |
Cutting Direction | Right Hand |
Series | 1028; Alumigator |
Centercutting | Yes |
Single Or Double End | Single |
Number Of Flutes | 3 |
Coating/Finish | ZrN |
Manufacturers Catalog Number | BNASU31000Z |
