Electronic Drop Indicator: 0 to 0.5″ Range Accurate to ±.00010″, Flat Back Calibrated
Item #: 14345367
Brand: Mitutoyo
Model #: 543-342BCAL
Product Specifications
| Back Type | Flat |
| Display Type | LCD |
| Accuracy (mm) | 0.0030 |
| Accuracy (Decimal Inch) | ?.00010 |
| Calibrated | Yes |
| Measuring Force (N) | 0 to 1.5 |
| Minimum Measurement (Decimal Inch) | 0.0000 |
| Maximum Measurement (mm) | 12.70 |
| Maximum Measurement (Inch) | 1/2 |
| Maximum Measurement (Decimal Inch) | 0.5000 |
| Power Source | Battery |
| Unit of Measure | Inch; Metric |
| Batteries Included | Yes |
| Number Of Batteries | 1 |
| Battery Size | CR2032 |
| Resolution (mm) | 0.001;0.01 |
| Resolution (Decimal Inch) | 0.00005;0.0001;0.0005 |
| Traceability Certification Included | Nist |
| Stem Diameter (Inch) | 3/8 |
| Features | Available in Metric & Inch/Metric Models |
| Includes | Plastic Case |
| Standards | ANSI |
| Series | 543 |
