1.28″ Max Depth, 0.236 to 2.559″ Width, External Left Hand Indexable Grooving/Cutoff Toolholder 5.906″ OAL, 20mm Shank Height, Uses SA 35-60\x85 Inserts, HSA Monoblock Toolholder, Series SA Parting / Grooving
Item #: 11429040
Brand: Arno
Model #: 101205
Product Specifications
| Internal or External | External |
| Maximum Depth of Cut (Decimal Inch) | 1.2800 |
| Maximum Depth of Cut (mm) | 32.50 |
| Hand of Holder | Left Hand |
| Maximum Groove Width (Decimal Inch) | 2.5590 |
| Minimum Groove Width (Decimal Inch) | 0.2360 |
| Minimum Groove Width (mm) | 5.99 |
| Toolholder Style | HSA Monoblock |
| Insert Holding Method | Screw |
| Insert Compatibility | SA 35-60? |
| Shank Height (mm) | 20.00 |
| Shank Width/Diameter (Decimal Inch) | 0.7870 |
| Series | Grooving; SA Parting |
| Overall Length (Decimal Inch) | 5.9060 |
| Head Length (Decimal Inch) | 1.2800 |
| Manufacturers Catalog Number | HSA 2020L-SA3506-65 |
| Coolant Through | No |
