Screw-Locking Inserts; Thread Size: #2-56; Thread Size: #2-56; Overall Insert Length (Decimal Inch): 0.5000; Insert Length: 0.5 in; Tang: Tangless; Length to Diameter Ratio: 2D; Number of Inserts: 5; Material: Stainless Steel; Material: Stainless Steel; F
Item #: 10320919
Brand: Recoil
Model #: TL23524L-5
Product Specifications
| Thread Size | #2-56 |
| Overall Insert Length (Decimal Inch) | 0.5000 |
| Insert Length | 0.5 in |
| Tang | Tangless |
| Length to Diameter Ratio | 2D |
| Number of Inserts | 5 |
| Material | Stainless Steel |
| Finish | Bright |
| Minimum Outside Diameter (Decimal Inch) | 0.11 in |
| Maximum Outside Diameter (mm) | 0.12 |
| Maximum Outside Diameter (Decimal Inch) | 0.12 in |
| Finish/Coating | Bright |
| Number of Free Coils | 7-3/8 |
| Maximum Locking Torque (oz-in) | 20 |
| Mininum Break Away Torque (oz-in) | 3.00 |
| Thread Standard | UNC |
| Material Grade | 304 |
